Fiberhome AN5516-01 OLT is a carrier-grade 10 Gigabit access device with EPON/GPON/10G EPON integrated supporting GE/10GE/STM-1/E1 uplink interface.

Brand	Fiberhome
Model No.	AN5516-01
Dimension	620 x 620 x 440mm
Power Supply Parameters	-48V DC input, supports dual power protection, Working Voltage range: -38.4V to -72V
Backplane Exchange Capacity	3.2 Tbit/s
Control Board Exchange Capacity	1920 Gbit/s
Access Capacity	12810G EPON, 6410G GPON, 128EPON, 256GPON, 768*GE
Operating Environment	Temperature: -25℃ to +55℃, Humidity: 5% to 95% (non-condensing)
Access Type	Upstream interface: 10GE optical, GE optical/electricity, Service interface: EPON optical port, GPON optical port, 10G EPON optical port, P2P FE optical port, P2P GE optical port, Ethernet optical interface
System Performance	Layer 2 / Layer 3 wire-speed forwarding, Supports static router /RIP/OSPE.MPLS, BITS/E1/STM-1/Ethernet/1588v2/1PPS+ToD clock, Maximum support 1:256 splitting ratio, Maximum support 60KM logical distance
